Reyee RG-EW1200G PRO 1300M Dual-band Gigabit Wireless Mesh Router

Wireless specifications

  2.4GHz 2*2: maximum rate 400Mbps; 5GHz 2*2: maximum rate 867Mbps

Antenna: External 6dBi non-removable omnidirectional antennas

Support 802.11a/b/g/n/ac/ac Wave2, MU-MIMO

Frequency band: Independent 2.4GHz and 5GHz modules, supporting dual frequency integration

Support beamforming

Wi-Fi channel:

2.4GHz Channel： 1,2,3,4,5,6,7,8,9,10,11,12,13

5GHz Channel： 36,40,44,48,149,153,157,161,165

Ports

1 10/100/1000M WAN port（Auto MDI/MDIX）

3 10/100/1000M LAN ports（Auto MDI/MDIX）

1 blue system LED indicator, 4 network port LED indicators

1 device pairing/factory reset button

1 power input interface

Physical specifications

Dimensions：220x140x36mm (W×D×H, excluding antennas)

Weight：0.98kg（entire equipment including packaging）

Power supply

Power specification: DC12V 1.5A

Maximum power: <14W

Certification

CCC，SRRC

Operating environment

Operating temperature: 0-45℃

Storage temperature: -40-70℃

Operating humidity: 5%-95%RH (non-condensing)

Storage humidity: 5%-95%RH (non-condensing)

Main features

Routing mode: PPPoE / DHCP / static IP; relay mode: wired relay / wireless relay

Obtain PPPoE account from the old router

Wi-Fi dual-band separation/ integration

Static DHCP address

Virtual server: port mapping, DMZ, etc.

DDNS: Oray

Network security

Wireless security: WPA-PSK/WPA2-PSK encryption

ARP protection: IP/MAC binding

SSID hiding

Preventing rogue devices (Blacklist/whitelist)

Internet access control

Advanced features

Reyee Mesh: Supports zero-configuration networking of multiple devices, and supports automatic switching between wired and wireless networking for multiple devices

Wi-Fi optimization: Wi-Fi roaming, 5G priority, acceleration mode, channel adjustment, power adjustment, roaming sensitivity adjustment

Bandwidth management: hardware NAT, intelligent bandwidth allocation

Auto network inspection, fault diagnosis

Software upgrade: Automatic & manual cloud software upgrade

Local web page

Management mode

Cloud management: MACC cloud platform

Ruijie Cloud app: iOS version, Android version
